ARIANEPLAST offers you its range of HIGH PERFOMANCE PLA!
A REVOLUTION in the world of FDM 3D printing, the PLA Ingeo 3D870!
The base resin resulting from extensive research and development by Natureworks is THE Ingeo grade specially and uniquely designed for 3D printing, combined with the technicality and manufacturing know-how of ARIANEPLAST, PLA Ingeo 3D870 is the best there is for 3D printing, stronger than ABS, specially developed for demanding technical applications!
- Great ease of printing, like all PLA
- No warping (even without heated plate)
- Increased printing speed by at least 50%
- High printing precision, even at high speed
- Solidity much greater than ABS (without any post-treatment)
- Possibility of annealing to further increase the resistance of the material
- Impact resistance up to 5x greater than that of ABS (After annealing)
- An excellent inter-layer bond which will give you solid, resistant, clean prints.
- Density of 1.22 g/cm3
The recommended temperature range is 210 to 230°C, because Ingeo 3D870 ARIANEPLAST PLA is more heat resistant than standard or HD PLA, moreover at higher temperatures the interlayer bonding of this filament is done at perfection, it also has a better aesthetic rendering of colors.
In terms of printing speed, numerous tests have been carried out and one of the specificities of the PLA Ingeo 3D870 is there because prints at 140mm/s have been made giving impressive quality results even in the smallest details. finer!
The PLA grade Ingeo 3D870 from Natureworks can be annealed offering significant advantages in terms of resistance to impact, heat (85°C after annealing), torsion, pressure, stretching, etc.< /p>
However, annealing requires good knowledge on this subject and is reserved for experienced Makers; it is not carried out haphazardly, at the risk of deforming the 3D printed objects or losing the dimensional stability of the part.
Annealing is done in an oven. You must ensure that it does not burn and that it never exceeds its crystallization point, i.e. the moment when it begins to deform.
The optimal temperature will depend on your oven, you will have to experiment but the secret is to heat a little but for a long time rather than the opposite.
Here is the table of recommended temperatures according to anumby .org: (higher temperatures are possible but there is a risk of deformation of the parts)
This is for guidance and information purposes only!!!
Heat resistance PLA Ingeo 3D870
Impact resistance of PLA Ingeo 3D870
(Please note, the values transmitted are results obtained after tests, values transmitted by ARIANEPLAST as informative indications and cannot be held responsible after any annealing problems)
In conclusion, Ingeo 3D870 ARIANEPLAST PLA is the most advanced and exceptional PLA material!
Beginners or experienced you will find the best of PLA with its complete technical characteristics and its great ease of printing.
Extrusion advice for PLA Ingeo 3D870 ARIANEPLAST:
- Standard nozzle
- Nozzle temperature: 230°
- Tray: 50° with platform preparation, if glass (clean) and DIMAFIX type fixative, etc…
- Printing Speed Range: 50 to 140mm/s (see even higher speed depending on your prints and your 3D printer)
